MAX 카메라

₩ 2,500,000 ~ 5,000,000

MTR3 CMOS Series TE-Cooling C-mount USB3.0

Standard C-Mount camera with SONY Exmor CMOS sensors from 0.5M to 45M;

Two-stage TE-cooling with controllable electric fan;

Sensor chip cooling up to 42°C below ambient temperature;

Working temperature can be regulated to specified temperature in 5 minutes;

Smart structure to assure the heat radiation efficiency and avoid the moisture problem;

IR-CUT/AR coated windows;

Up to 1 hour long time exposure;

USB3.0 5Gbit/second interface ensuring high speed data transmission;

Ultra-FineTM color engine with perfect color reproduction capability;

With advanced video & image processing application

NEOview;

Support both video and trigger modes;

MTR3CMOS Series TE-Cooling C-mount USB3.0 CMOS Camera

The MTR3CMOS adopt SONY Exmor CMOS sensor as the image-picking device and USB3.0 is used as the transfer interface. MTR3CMOS hardware resolutions range from 0.5M to 45M and come with the integrated CNC aluminum alloy compact housing.

With the two-stage peltier cooling sensor chip to -42 degree below ambient temperature. This will greatly increase the signal to noise ratio and decrease the image noise. Smart structure is designed to assure the heat radiation efficiency and avoid the moisture problem. Electric fan is used to increase the heat radiation speed.

MTR3CMOS comes with advanced video & image processing application ToupView; Providing Windows/Linux/macOS/ Android multiple platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc);

The MTR3CMOS can be widely used in low light environment and microscope fluorescence image capture and analysis, as well as the astronomy deep sky application.

Dimension of MTR3CMOS Series Camera

Installation drawings(Click to enlarge). The MTR3CMOS body, made from CNC alumnium alloy, ensures a heavy duty, workhorse solution. The camera is designed with a high quality IR-CUT to protect the camera sensor. No moving parts included. This design ensures a rugged, robust solution with an increased lifespan when compared to other industrial camera solutions.
